The fence is made of woven steel wire, which is one of the most commonly used and versatile of all the fencing fabrics. It is normally available in a variety of wire gauges and mesh sizes to suit individual applications. All chain link rolls come complete with line wires and with knuckled edges. Barbed (protruding) edges increase the security of the fencing and are available to order.
Mesh Rolls
| Mesh | Wire Thickness | Surface Treatment | Panel Width | Height |
|
40x40mm 50x50mm 60x60mm 65x65mm 75x75mm |
2.0mm - 4.8mm |
Galvanized and PVC coated or Hot dipped galvanized |
10m 15m 18m 20m 25m 30m |
1200mm |
| 1500mm | ||||
| 1800mm | ||||
| 2000mm | ||||
| 2100mm | ||||
| 2400mm | ||||
| 2500mm | ||||
| 3000mm | ||||
| 3600mm |
Post-Round post
| Profile | Wall Thickness | Surface Treatment | Length | Rainhat |
| Φ60 |
1.50mm - 5.20mm |
Galvanized and Electrostatic polyester powder coated Or Hot dipped galvanized |
On the basis of panel height | Metal |
| Φ75 |
Note : Normally single branch crack or V type crack will be installed at top of the post, barbed wire and razor wire will be fixed at top of the fence to
